We have a limited number of these units available as "open box"
WyreStorm 1 x 2 HDMI to HDMI Splitter



- Professional grade
- Full 1080p support
- HDCP compliant
- 3D support (Frame sequential - Blu ray / Interlaced stereoscopic - satellite/cable braodcasts)
- Range of models to suit install
- Can be cascaded to make large distribution system
- Compact design with mounting brackets supplied

Overview
The WyreStorm SP-0102 is a two-output HDMI splitter that uses an asynchronous method of transmission to distribute the connected HDMI input to two asynchronous outputs – otherwise known as a start-stop transmission – for effective and timely transmission of HD signals.*
The SP-0102 also buffers and amplifies the signal to ensure optimum transmission and reception over distances up to 15m / 49ft (the typical recommended transmission distances for HDMI cables).
Compact for unobtrusive installations, the SP-0102 is also fully cascadable so multiple units may be combined to create a larger HD distribution.
*The asynchronous method of communication between devices is advantageous in HD distribution as signals can be transmitted intermittently without requiring intervals of validation on reception as with a continuous data stream, allowing signals to be more efficiently received at the display end.
Features:
- Compact size for neat, unobstrusive installations - only 8.9cm x 6.7cm
- Simple plug and play connection - no settings required
- Visbible LED Input/Output status
- Distribution: 2 asynchronous HDMI outputs
- Output auto-switching function - no buttons or switches on the unit to be set
- units can be cascaded (daisy-chained)
- Signaling rates up to 6.75Gbps in support of WUXGA and 1080p Deep color displays
- 8dB receiver equalization to compensate for 5m /16ft reduction in signal quality if transmitting over recommended 15m/49ft HDMI cable distances
- 3dB driver pre-emphasis to compensate for PCB losses
- Each port supports HDMI or DVI signals Non-4k
- 1 year warranty
In the Box
- 1 x WyreStorm SP-0102 HDMI Splitter
- 1 x 5VDC Power Supply
- Mounting brackets
Specifications
Retail :$49.95
Buy It Now :$49.95
Please email or call if you have any questions
