Wyrestorm EXP-SP0102-101 1x2 1080p Split 1 HDMI to 2 Sets! Open Box Item

  • Sale
  • $49.95

We have a limited number of these units available as "open box"

Packed in original cartons with all accessories!

WyreStorm 1 x 2 HDMI to HDMI Splitter

Part Number SP-0102

The WyreStorm Standard HD Splitter Range are professional grade single and dual input splitters that provide distribution and replication of HD input to multiple duplicate displays - perfect for Retail AV, Commercial and Hospitality installation. The fact our R&D team work on all products across our entire product range, it is possible to mix and match HD Splitters with extender sets to cover large screen installations quickly and cost effectively.   Features include:
  • Professional grade
  • Full 1080p support
  • HDCP compliant
  • 3D support (Frame sequential - Blu ray / Interlaced stereoscopic - satellite/cable braodcasts)
  • Range of models to suit install
  • Can be cascaded to make large distribution system
  • Compact design with mounting brackets supplied


The WyreStorm SP-0102  is a two-output HDMI splitter that uses an asynchronous method of transmission to distribute the connected HDMI input to two asynchronous outputs – otherwise known as a start-stop transmission – for effective and timely transmission of HD signals.*

The SP-0102 also buffers and amplifies the signal to ensure optimum transmission and reception over distances up to 15m / 49ft (the typical recommended transmission distances for HDMI cables).

Compact for unobtrusive installations, the SP-0102 is also fully cascadable so multiple units may be combined to create a larger HD distribution.

*The asynchronous method of communication between devices is advantageous in HD distribution as signals can be transmitted intermittently without requiring intervals of validation on reception as with a continuous data stream, allowing signals to be more efficiently received at the display end.


  • Compact size for neat, unobstrusive installations - only 8.9cm x 6.7cm
  • Simple plug and play connection - no settings required
  • Visbible LED Input/Output status
  • Distribution: 2 asynchronous HDMI outputs
  • Output auto-switching function - no buttons or switches on the unit to be set
  • units can be cascaded (daisy-chained)
  • Signaling rates up to 6.75Gbps in support of WUXGA and 1080p Deep color displays
  • 8dB receiver equalization to compensate for 5m /16ft reduction in signal quality if transmitting over recommended 15m/49ft HDMI cable distances
  • 3dB driver pre-emphasis to compensate for PCB losses
  • Each port supports HDMI or DVI signals Non-4k
  • 1 year warranty

In the Box

  • 1 x WyreStorm SP-0102 HDMI Splitter
  • 1 x 5VDC Power Supply
  • Mounting brackets


88mm/3.4" x 28mm/1.1" x 68mm/2.7"
-5 to +35°C (-41 to +95 °F)
5 to 90 % RH (no condensation)
0.5-1.0 volts p-p
5 volts p-p (TTL)
1080p 24bit colour depth
1080p transmission over 15m / 49ft - perfect transmission conditions denote a straight cable run within specified distance range of both product and cable with no obstructions or stress placed on the HDMI cable. Lengthen HDMI transmission still further by using a WyreStorm HDMI to HDMI coupler (see accessories
VESA: 640x480, 800x600,1024x768, 1280x1024, 1600x1200, 1920x1200 DTV/HDTV: 480i/576i/480p/576p/720p/1080i/1080p
HDMI v1.3a + HDCP1.0/1.1
DTS-HD Master Audio, Dolby True HD, multi-channel 5.1, 7.1, stereo
5VDC - from mains or USB 5V power adapter
1.5Watts (Max.)

   Retail :$49.95
Buy It Now :$49.95

Please email or call if you have any questions

Store Phone 800-826-0520



  • Free shipping to lower 48 states only. AK HI PR and international buyers please contact us for accurate shipping rates.
  • All packages are shipped Double-Boxed and Fully Insured to guarantee  safe delivery
  • Please note, our policy is to ship only to the credit card billing address. If you are paying with Pay Pal your address must be confirmed.
  • If item needs to be shipped to an alternate address, please contact us for approval, prior to purchase.
  • Packages are shipped by FedEx ground service. FedEx Express available for air shipments. For details, please contact us with your zip code and service request..

  • Payment

    For your convenience, the following methods are accepted for payment:

  • Pay Pal
  • Call 800-826-0520 to pay by credit cards directly
  • Returns

  • Defective items will be exchanged within 14 days from delivery. After 14 days, please contact the manufacturer.
  • Defective item returns must be in the manufacturer's original packaging, in like new condition, including all packaging material, shipped double boxed and fully insured
  • Item is guaranteed to be as described. If a refund is desired, we will refund your full purchase minus a 15% restocking fee.  The item must be as-sold, unopened, and in a re-sellable condition. Return shipping costs to seller will be the buyer's responsibility. Please contact us with any questions in advance.
